AEROCUT DIGITAL FINISHING SYSTEMS
Prepress to post-press… we have you covered!®
As the world of on-demand printing continues to evolve, so too does MBM Corporation.
MBM has assembled a collection of finishing solutions ideally suited for the digital realm. From cutting to creasing to folding, MBM has your digital finishing covered. And when you’re ready to move up to single-pass slitting, cutting, creasing, scoring, and perfing look no further than the Aerocut digital finishing solutions line. These all-in-one finishing systems will take your digital production to the highest level.
Automatically Program Your AeroCut with Intellicut
Learn about Intellicut ready Aerocut systems
-
Aerocut X Pro
- Sheet Capacity: 4"*
- Speed: 34 sheets/min.*
- Electrical Req.: 100 - 120 V, 50/60 Hz.
- Paper Size: 8.27" x 8.27" to 14.5" x 47.2"**
- Paper Weight: 120 - 400 gsm. / 6 - 16 pt.*
- Dimensions (D x W x H): 28" x 46.3" x 42.3"
- Shipping weight: 639 lbs.
-
Aerocut X
- Sheet Capacity: 4"*
- Speed: 24 sheets/min.*
- Electrical Req.: 100 - 120 V, 50/60 Hz.
- Paper Size: 8.27" x 8.27" to 14.5" x 47.2"**
- Paper Weight: 120 - 400 gsm. / 6 - 16 pt.*
- Dimensions (D x W x H): 30" x 41.8" x 42.3"
- Shipping weight: 595 lbs.
-
Aerocut NanoPlus
- Sheet Capacity: 1.2"
- Paper Size: 8 1/4" X 8.1/4" to 13" X 19"
- Paper Weight: 120 - 350 gsm / 6 -14 pt.*
- Speed: 20 sheets/min.*
- Electrical Req.: 120 V. 60 Hz.
- Dimensions (D x W x H): 24 7/8" x 30 1/4" x 39 7/8"
- Shipping weight: 212 lbs.
-
AeroDieCut
- Sheet Capacity: 3.9"
- Paper Size: 14.3" x 20.25"
- Paper Weight: 120 - 400 gsm. / 6 - 16 pt.*
- Speed: 1,000 sheets per hour
- Electrical Req.: 100 - 120 V, 50/60 Hz.
- Dimensions (D x W x H): 106" x 42" x 43"
- Shipping weight: 903 lbs.
FOLDERS
MBM’s folder line features machines for corporate applications.
MBM tabletop folders offer the perfect combination of speed, precision, and ease of use, making them ideally suited for small offices, schools, and corporate environments. Automatic programmable models store fold programs in memory and can be set up to run at the touch of a button.
-
352S
- Dimensions (D x W x H): 22 1/4" x 51 1/4" x 43 1/2"
- Sheet Capacity: 450*
- Electrical Req.: 115 V. 60 Hz., 20-amp dedicated line
- Paper Size: 3 3/8" x 4 3/4" to 12 5/8" x 17 3/4"
- Shipping weight: 312 lbs.
- Speed: 30,000 per/hr.*
- Paper Weight: 13 to 110 lbs.*
-
352F
- Dimensions (D x W x H): 22 1/4" x 41 3/4" x 14 1/2"
- Sheet Capacity: 300*
- Electrical Req.: 115 V. 60 Hz.
- Paper Size: 2" x 2 3/4" to 14 x 21 1/4"
- Shipping weight: 105 lbs.
- Speed: 22,000* per/hr
- Paper Weight: 13 to 110 lbs.*
-
1800S
- Dimensions (D x W x H): 24" x 49" x 23"
- Sheet Capacity: 800*
- Electrical Req.: 120 V. 60 Hz.
- Paper Size: 4 1/2" x 8 1/4" to 13" x 19"
- Shipping weight: 189 lbs.
- Speed: 18,000 sheets per hour*
- Paper Weight: 16 to 80 lbs.*
-
508A
- Sheet Capacity: 500*
- Dimensions (D x W x H): 21 1/2" x 39 3/4" x 19 3/4"
- Electrical Req.: 115 V. 60 Hz.
- Paper Size: 3 1/2" x 5" to 11" x 17"
- Shipping weight: 82 lbs.
- Speed: Up to 14,400 sheets per hour*
- Paper Weight: 12 to 80 lbs.*
-
408A
- Sheet Capacity: 500*
- Dimensions (D x W x H): 21 1/2" x 39 3/4" x 19 3/4"
- Electrical Req.: 115 V. 60 Hz.
- Paper Size: 3 1/2" x 5" to 11" x 17"
- Shipping weight: 76 lbs.
- Speed: Up to 14,400 sheets per hour*
- Paper Weight: 12 to 80 lbs.*
-
208J
- Sheet Capacity: 500*
- Dimensions (D x W x H): 21 1/2" x 40 5/8" x 19 3/4"
- Electrical Req.: 115 V. 60 Hz.
- Paper Size: 3 1/2" x 5" to 11" x 17"
- Shipping weight: 73 lbs.
- Speed: Up to 14,400 sheets per hour*
- Paper Weight: 12 to 80 lbs.*
TRIUMPH TRIMMERS
Manufactured in Germany by MBM’s parent company, Krug & Priester, Triumph trimmers are built to the same exacting tolerances as Triumph cutters. All trimmers feature sturdy, all-metal construction and the finest Solingen steel blades.
Every Triumph trimmer features stationary or movable transparent Lexan safety guards. All models are tested by independent safety labs and comply with all applicable international safety regulations. Triumph trimmers are certified under a quality management system established in all company areas under the DIN EN ISO 9001:2008 standards.
-
TRIUMPH 1110
- Sheet Capacity: 20* (5/32" cutting height)
- Dimensions (D x W x H): 55 3/4” x 32 1/2” x 53 1/2” (41 3/4" W with fold-away extension table in working position)
- Shipping weight: 182 lbs.
- Cuting Width: 43 1/4"
- Table Size: 43 1/4" x 30"
- Blade Material: Solingen steel
-
TRIUMPH 1171
- Sheet Capacity: 40*
- Dimensions (D x W x H): 38" x 21 1/4" x 20 1/2"
- Shipping weight: 62 lbs.
- Cuting Width: 28"
- Table Size: 30" x 20"
- Blade Material: Solingen steel
-
TRIUMPH 1158
- Sheet Capacity: 40*
- Dimensions (D x W x H): 31" x 16" x 10"
- Shipping weight: 42 lbs.
- Cuting Width: 22 1/2"
- Table Size: 23 3/4" x 14"
- Blade Material: Solingen steel
-
TRIUMPH 1046
- Sheet Capacity: 30*
- Dimensions (D x W x H): 27 1/2" x 15 1/4" x 15"
- Shipping weight: 20 lbs.
- Cuting Width: 18"
- Table Size: 20" x 14"
- Blade Material: Solingen steel
-
TRIUMPH 1138
- Sheet Capacity: 50*
- Dimensions (D x W x H): 22 1/2" x 16" x 10"
- Shipping weight: 29 lbs.
- Cuting Width: 15"
- Table Size: 16" x 14"
- Blade Material: Solingen steel
-
TRIUMPH 1135
- Sheet Capacity: 25*
- Dimensions (D x W x H): 23" x 13 3/8" x 12 3/4"
- Shipping weight: 13 lbs.
- Cuting Width: 13 3/4"
- Table Size: 15" x 12"
- Blade Material: Solingen steel
-
TRIUMPH 0135
- Dimensions (D x W x H): 19" x 60 1/2" x 37"
- Shipping weight: 84 lbs.
- Cuting Width: 53"
- Table Size: 34" x 11 1/2"
- Blade Material: Solingen steel
- Cutting Height: 1/32"
-
TRIUMPH 1030
- Sheet Capacity: 5-6*
- Dimensions (D x W x H): 8" x 18 3/4" x 2 3/8"
- Shipping weight: 2 lbs.
- Cuting Width: 13"
- Table Size: 6 1/2" x 13"
- Blade Material: Solingen steel
CREASERS
Perfect for digital applications, the GoCrease creasers allow documents printed on heavy or coated stock to be creased prior to folding, creating a crisp more accurate fold with no cracking
-
GoCrease SEMI
- Dimensions (D x W x H): 23 1/2" x 45" x 12"
- Shipping weight: 120 lbs.
- Min Max Working Width: 4 to 18"
- Paper Weight Creasing: 80 - 400 gsm
- Channel Width: 0.04 / 0.05 / 0.063
- Electrical Req.: 110 V. 60 Hz.
- Speed: 1,500 sheets/hr.*
- Country of Origin: Czechia
-
GoCrease 4000
- Dimensions (D x W x H): 23 1/2" x 28" x 12"
- Electrical Req.: 110 V. 60 Hz.
- Shipping weight: 92.6 lbs.
- Min Max Working Width: 1 to 18"
- Paper Weight Creasing: 80 - 400 gsm
- Channel Width: 0.04 / 0.05 / 0.063
- Country of Origin: Czechia
-
GoCrease 3000
- Dimensions (D x W x H): 14 1/2" x 19" x 15 1/2"
- Shipping weight: 27.5 lbs.
- Min Max Working Width: 1 to 12 5/8"
- Paper Weight Creasing: 80 - 400 gsm
- Channel Width: 0.04 / 0.05 / 0.06
- Country of Origin: Czechia
BOOKLETMAKERS
Speed and versatility are the hallmarks of MBM bookletmakers and finishing systems. Our Sprint 3000 model enjoys a solid reputation in the print finishing industry for performance and dependability. The revolutionary SF2 bookletmaker utilizes wire-fed stitching technology previously found only in larger systems costing up to three times more.
The Sprint 3000 bookletmaker has long been regarded as tops in the industry. Paired with an optional trimmer, it may be combined with a variety of collators including the MBM FC 10 for a complete document finishing system. It features easy set-up and adjustment, variable speed, and powered exit conveyors. The SF2 bookletmaker utilizes a patented wire-fed stitching system that eliminates the need for pre-formed staples. This low maintenance machine jogs, stitches, and folds up to 65,000 booklets before the spools need replacing. An optional trimmer can be combined with the SF2 for the ultimate booklet finishing system.
-
SPRINT 3000
- Dimensions (D x W x H): 23" x 46" x 36" (20" W with conveyor stored)
- Electrical Req.: 115 V. 60 Hz.
- Paper Size: 5 1/2" x 8" to 12" x 18"
- Shipping weight: 280 lbs.
- Sheet Capacity: 25*
- Speed: 1,500 sets/hr*
-
iBooklet
- Paper Weight: 16 to 80 lbs.*
- Dimensions (D x W x H): 19 5/8" x 19 5/8" x 15 11/16"
- Paper Size: 4 1/8" x 8 1/4" to 13" x 18 7/16"
- Shipping weight: 55 lbs.
- staple_mode: saddle, side, corner staple
- Sheet Capacity: Up to 16*
-
Stitchmaster
- Dimensions (D x W x H): 15" x 16" x 24"
- Electrical Req.: 115 V. 60 Hz.
- Paper Size: 2" x 2" to 11" x 17"
- Shipping weight: 50 lbs.
- Sheet Capacity: 60*
COLLATORS
The FC 10 Automatic Collator is one of the most versatile collators on the market today. Reliable and easy to use, it interfaces with a variety of bookletmakers including the MBM Sprints and SF2 series.
A variety of performance enhancing options are available for the FC 10. The corner stapler attachment is capable of stapling up to 10 sheets at a time. A heavy-duty base mounted on casters allows easy mobility. The FC 10 is certified by Underwriters Laboratories for the US and Canada.
SUPPORT PRODUCTS
MBM’s line of print finishing support products includes paper joggers, pressure sealers, drills, and everything needed for the ultimate finishing system.
The AJ 700 air-feed paper jogger forces air between sheets to reduce jogging time and eliminate powder buildup and static. It also allows press sheets and digital copies to be dried immediately after printing to prevent offset. MBM drills feature a deep, 2-inch drilling capacity and movable tables mounted on bearings for precise paper positioning.
-
MX17000 Pressure Sealer
- Paper Weight: 20 - 30 lbs.
- Feeder Capacity: 1,400 sheets
- Form Sizes: Depth - up to 14" / Width - up to 9"
- Shipping weight: 300 lbs.
- Dimensions (D x W x H): 27" x 20" x 43"
- Speed: Up to 17,000 per hour
-
IM 8500 Pressure Sealer
- Paper Weight: 16-30 lbs.
- Feeder Capacity: 700 in standalone mode
- Form Sizes: Up to 14" depth, up to 9" width
- Electrical Req.: 110 V. AC.
- Shipping weight: 106 lbs.
- Dimensions (D x W x H): 17" x 24" x 15"
-
ES 8500 Pressure Sealer
- Paper Weight: 20-28 lbs.
- Feeder Capacity: 700 pressure seal forms
- Form Sizes: Up to 14" depth, up to 9" width
- Electrical Req.: 110 V. AC.
- Shipping weight: 115 lbs.
- Dimensions (D x W x H): 17" x 24" x 15"
- Speed: 9,000 forms per hour
-
ES 5500 Pressure Sealer
- Feeder Capacity: 150 pressure seal forms
- Form Sizes: Up to 14" depth, up to 9" width
- Electrical Req.: 110 V. AC.
- Shipping weight: 54 lbs.
- Dimensions (D x W x H): 13" x 15" x 11"
- Speed: 5,500 forms per hour
-
ES 2500 Pressure Sealer
- Electrical Req.: 115 V. 60 Hz.
- Feeder Capacity: 150 pressure seal forms*
- Shipping weight: 80 lbs.
- Dimensions (D x W x H): 13" x 15" x 11"
- Speed: 3,000 forms per hour
- Form Sizes: Up to 14" depth, up to 9" width
-
FMM3 Drill
- Electrical Req.: 115 V. 60 Hz.
- Shipping weight: 292 lbs.
- Dimensions (D x W x H): 32" x 15" x 52"
- Table Size: 32" x 15"
- Drilling Capacity: 2"
- Max paper length: 32"
- Max throat depth: 3 3/4"
-
AJ 700 Jogger
- Electrical Req.: 115 V. 60 Hz.
- Shipping weight: 84 lbs.
- Dimensions (D x W x H): 22" x 17" x 45 1/4"
- Paper Size: 5"x 7 3/8" to 12 7/8" x 17 3/4"
- Sheet Capacity: 1,000*
-
JT7 Jogger
- Electrical Req.: 115 V. 60 Hz.
- Shipping weight: 46 lbs.
- Dimensions (D x W x H): 21" x 12 1/2" x 17 1/4"
- Speed, Sheet per hour: 30,000*
- Paper Size: 5"x 7 3/8" to 12 7/8" x 17 3/4"
- Sheet Capacity: 1,000*
